■ ISO 9001 certified quality management system, CE approved
■ Suitable against class A and class B.
■ All fire extinguishers must be serviced in accordance with BS5306
■ Polyester powder external coating (Red, Cream).
■ Polyester powder Internal coating(Gray).
■ All fire extinguishers are tested no leakage.
■ Chemical Agent: AFFF3% Foam, Pressured with nitrogen gas.
■ Working Pressure: 15Bar. Test Pressure: 35Bar.
■ EN1866-1 Approved
Specification
| Stored Type | External Type | |
| Capacity | 25L | 100L |
| Item No. | PSE28-01 | PSE28-02 |
| Out-dia.(mm) | 270 | 406 |
|
Cyinder Length (mm) |
625 | 1100 |
|
Cylinder Weight (kg) |
20 | 50 |
|
Extinguisher Weight (kg) |
55 | 160 |
| Volume (L) | 30 | 124 |
|
Filled Weight (kg) |
25 | 100 |
|
Temperature Range |
0+55℃ | 0+55℃ |
|
Working Pressure (bar) |
15 | 15 |
|
Testing Pressure (bar) |
35 | 35 |
|
Min Wall- Thickness (mm) |
2.5 | 3.0 |
| Material |
HP295/B440HP |
HP295/B440HP |
| Fire Class | 55A 1BC | 55A 3BC |
| Carton Size (cm) | 44x45x95 | 62x57x122 |
■ ISO 9001 certified quality management system, CE approved
■ Suitable against class A and class B.
■ All fire extinguishers must be serviced in accordance with BS5306
■ Polyester powder external coating (Red, Cream).
■ Polyester powder Internal coating(Gray).
■ All fire extinguishers are tested no leakage.
■ Chemical Agent: AFFF3% Foam, Pressured with nitrogen gas.
■ Working Pressure: 15Bar. Test Pressure: 35Bar.
■ EN1866-1 Approved
